Great news for automotive locksmiths and key programmers! The KeyDIY KD-X4 key programmer has just received a major update that extends its capabilities to cover 2018 and newer Jaguar and Land Rover smart key systems. This new functionality allows you to copy or clone smart keys for these premium vehicles quickly and efficiently, without the need for complex and time-consuming procedures.
In this article, we'll walk you through everything you need to know about this exciting new feature—from the key advantages it offers to a step-by-step guide on how to use it.
What's New: KD-X4 Supports 2018+ JLR Smart Key Cloning
The KeyDIY KD-X4 is already well-known as a versatile 5-in-1 key programming tool that handles recognition, generation, copying, programming, and matching for a wide range of vehicles. With this latest update, the KD-X4 now supports cloning smart keys for 2018+ Jaguar and Land Rover models equipped with NXP NCF29Ax chips.
This is a game-changer for locksmiths who frequently work on JLR vehicles, as it eliminates many of the traditional hurdles associated with key programming for these brands.
Key Advantages of the New JLR Feature
The new KD-X4 update brings several significant benefits to the table:
- No KVM Module Disassembly Required: Unlike many traditional methods that require you to remove and disassemble the KVM (Keyless Vehicle Module) module, the KD-X4 approach works without this labor-intensive step.
- No Online Programming Needed: The process does not rely on online servers or dealer-level authorization, which means you can perform the cloning offline and without the risk of code tracking or server downtime.
- Broad Compatibility: The function works with both original JLR smart keys and third-party alternatives like KD ZB smart keys, giving you flexibility in sourcing replacement keys.
- Simplified Workflow: The KD-X4 app provides clear on-screen wiring diagrams and step-by-step guidance, making the process accessible even for technicians who are new to JLR key programming.
How to Clone a 2018+ JLR Smart Key with KD-X4
Here's a general overview of the key cloning process using the KD-X4 and the optional NCF29Ax adapter. The procedure is similar to what you might be familiar with from tools like the CGDI K2.
Step 1: Prepare the Original Key
Start by carefully disassembling the original Jaguar or Land Rover smart key to access the circuit board.
Step 2: Connect to the KD-X4 App
Launch the KD-X4 application on your mobile device or tablet. Navigate to the Land Rover Smart Key Synchronization function.
Step 3: Select the Key Type
Within the app, choose Land Rover → Select by Type → Disassemble to Copy Key → Copy Smart Key. The app will then display the wiring diagram for your specific key model.
Step 4: Connect to the Key Board
You have two options at this stage:
- Direct Soldering: Solder wires directly to the key board following the diagram provided by the KD-X4 app.
- Use the NCF29Ax Adapter (Recommended): Desolder the NXP NCF29Ax chip from the original key's circuit board and place it into the KD's NCF29Ax adapter. This method is cleaner and reduces the risk of damaging the board.
Step 5: Read and Save the Original Data
Using the KD-X4, read the chip data from the original key and save it securely.
Step 6: Write Data to the New Key
Replace the original key with a new key (either an original or a KD ZB smart key). Connect the new key and write the saved original data onto it.
Once the data is successfully written, your new key will function as a clone of the original.
What About RFA Module Programming?
It's worth noting that the KD-X4 also supports related JLR operations, such as writing initialization data to the SPC560B60L3 chip used in JLR KVM/RFA modules. With the optional KEYDIY SPC560B60L3 programming socket, you can program these chips without any soldering. This makes the KD-X4 a comprehensive solution for JLR key and immobilizer work.
Supported Systems
The new JLR cloning feature covers a wide range of 2018+ models, including those using JPLA, K8D2, J9C3, and M9R3 keyless go systems. This ensures broad coverage across the Jaguar and Land Rover lineup.
Final Thoughts
The addition of 2018+ Jaguar and Land Rover smart key cloning to the KeyDIY KD-X4 is a significant upgrade that makes this already powerful tool even more indispensable. Whether you're a professional locksmith or an automotive workshop, this new feature saves time, reduces complexity, and expands the range of services you can offer.
Keep an eye on the KD-X4 app for the latest updates, and make sure you have the necessary accessories—like the NCF29Ax adapter and the SPC560B60L3 programming socket—on hand to take full advantage of these new capabilities.
